New Promotional Waterpoof Led Cabinet p6 outdoor led screen

FOB Reference Price:Get Latest Price
US $75-88 / Piece | 1 Piece/Pieces (Min. Order)
Supply Ability:
1000 Piece/Pieces per Week
Port:
shenzhen
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
LIGHTIN
Model Number:
LTI-P6
Usage:
led screen assembly
Tube Chip Color:
Full Color
Display Function:
Video
Pixels:
6mm
Size of Cabinet:
768mm*768mm
Weight of Cabinet:
13kg
Cabinet:
Aluminnium material
Packaging & Delivery
Packaging Details
1, wooden case
2, flight case
Delivery Time
8 working days

Stage LED Display SMD P6















Specification:



Model

P6 Outdoor LED Display Screen

NO.

Items

Specifications

1

Pixel Pitch(MM)

6

2

Pixel Composition

SMD3in1

3

LED Encapsulation Type

SMD5050

4

LED Chip Sizes

12+13+13(RGB) Epistar + Silan + Nicha + Opto

5

Pixel Density(Dots/M2)

27777

6

Module Size(MM)

192 x 96

7

Module Resolution(Dots)

32 x 16

8

Cabinet Size(MM)

960 x 960

9

Cabinet Resolution(Dots)

96 x 96

10

Maximum Brightness

10000cd/sqm

11

Before Dot to Dot Correction

8000cd/sqm

12

After Dot to Dot Correction

7000cd/sqm

13

Brightness Adjustment Range

Manually, Auto Stepless Continuous Adjustment, 14 levels Adjustment without Gray Scale Loss

14

Color Temperature Adjustable

3200K - 10000K

15

Best View Distance(M)

4m - 100m

16

Horizontal View Angle

120 deg

17

Vertical View Angle

60 deg

18

Signal Processing

16bit

19

Control Mode

Synchronization

20

Driving Mode

Static Constant Current

21

Contrast

3000:1

22

Colors

281 Trillion Billion

23

Gray scale per colors

65536 level

24

Video Frame Frequency

More than 60HZ

25

Refresh Rate

More than 3000HZ

26

Lifetime

100000 Hours

27

Maximum Power Consumption

Less than 700 w

28

Average Power Consumption

Less than 300 w

29

Cabinet Weight(without Steel Structure)

30 Kg

30

Compatible Signals(with video processor)

X Composite, X Component, RGB,SDI,HDSDI,DVI,AV, S-Video, VGA, HDMI, DP

31

Working Voltage

100-240V/AC 50/60HZ

32

Environment Temperature

–20 deg / +60 deg

33

Storage Temperature

–40 deg / +60 deg

34

IP Protection Rate

Front IP68, Rear IP65

35

Screen Surface Evenness

Less than 0.5mm

36

Working Humidity

10-99 percent

37

Storage Humidity

10-99 percent

38

Malfunction Dot Rate

Less than 0.0001

39

Display Screen Signals

RF, S-Video, RGB, RGBHV, YUV, YC, COMPOSITION

41

Wind Resistance

Level 12

42

Shock Resistance

Level 8



2.Features:

1>Price Advantage

We use Entire automatic equipment, so each month; we can up to 1000sqm,

In this case, the cost of purchase material is lower than others.

2>Good quality raw material

LED: Adopting low current, high brightness LED, body antistatic >1000V, LED scope wavelength with in 5nm, so the screen with reliable performance, good consistency, fast response time and long life time.

Mask: All designed by ourselves, using good PC material, not easy to deform

3>Convenient installation

We prepare a full-set installation manual and free training, which will make you easy to install and operate the screen.

4>Good after-sale service

two years warranty, lifetime maintain, During the warranty .lifetime maintain, During the warranty time, all broken parts caused by the quality problem could be replaced by us free of charge.
